| Installed width EB | 12.5 |
| Installed width / cabinet body side thickness | EB 12.5 (cabinet body side thickness 16 mm) |
| Mounting side | left and right |
| Load class | 25 kg |
| Type of runner | Concealed runner |
| Type of drawer runner | Partial extension runner |
| User friendly features | Silent System |
| Components | Drawer runners |
| Material | steel |
InnoTech Atira IS144 Internal Drawer
S$97.60 – S$100.60
Quadro 25 Partial Extension
S$29.00 – S$29.90
- Partial extension runner
- Slide on installation
- Load capacity to EN 15338 Level 3
- Galvanised steel
Description
Shipping & Delivery
Related products
Actro YOU
Runner Systems, Actro YOU, Actro YOU - 40kg - Full Extension, Actro YOU - 70kg - Full Extension, AvanTech YOU - Runner, Drawer Systems
- Full extension runner for combining with AvanTech YOU system drawer or wooden drawer with catches
- Integrated Silent System
- Optional: Push to open Silent
- Load classes XS (10 kg) / L (40 kg) / XL (70 kg)
- Load capacity to EN 15338, Level 3
- Galvanised steel
- Push to open Silent for Actro YOU can be ordered separately
- Catch for use with wooden drawer can be ordered separately
Push to open Silent opening system
- Can be used with AvanTech YOU system drawer on Quadro V6 YOU drawer runner with Silent System
- Can be used with wooden drawer on Quadro V6 5D drawer runner and Quadro V6 YOU drawer runner with Silent System
- Synchronisation bar to be ordered separately
- Connector for synchronisation bar to be ordered separately
- 1 Push to open Silent unit, left and right
- 1 activator, left and right
- 2 adapters for synchronisation
Quadro V6 30kg Silent System
- Slide on installation with catches and tool-less height adjustment
- Integrated Silent System
- Optional: catch and plug for pull-out shelves
- Suitable for drawers with a side profile thickness of up to 19 mm
- Platform concept: identical cabinet body, drawer and front panel dimension for Quadro partial and full extension runners for slide on installation
- Load capacity to EN 15338, Level 3
- Galvanised steel
